Applicable materials: Enclosed protective cover raycus laser cutting gold and silver 50w is suitable for marking all metal materials and most of non-metal materials. Enclosed protective cover raycus laser cutting gold and silver 50w machine is widely applied to many industries, such as Electronics, Auto parts & hardware, handcrafts, packing and so on. l Electronic and communication products, IC products, electric lines, cable computer components and electric appliances. l Automobile and motorcycle parts, instrumentation, aerospace, military products, hardware machinery, medical instruments, measuring and cutting tools. l Handicrafts, Jewelry, garments, glasses, instruments, gifts, office devices, brand scutcheon, sanitary ware appliances and other workpieces. l The packing for dishware, food, drinking, smoking and alcohol, etc....
Competitive Advantage:
Specifications:
|
Product model |
MZ-FMP10 |
MZ-FMP20 30 50 |
|
Type of machine |
raycus laser marking machine |
|
|
Laser Wavelength |
1064nm |
|
|
laser power |
10W |
20W 30W 50W |
|
Modulating frequency |
20KHz—100KHz |
|
|
Marking Range: |
110mm×110mm 175mm×175mm 210mm×210mm |
|
|
Repetition Precision |
±0.001 |
|
|
Marking mode |
static or dynamic |
|
|
Spot diameter |
0.025mm |
|
|
Lifting way of working table |
Manual or automatic |
|
|
Lifting height |
500mm |
|
|
Travel of table |
X:150mm Y: 90mm |
|
|
Machine power supply |
220V 50Hz 20A |
|
|
Cooling method |
forced-air cooling |
|
|
Power of the Whole Equipment |
<0.5KW |
|
|
working conditions |
temperature:13°C~29°C, humidity:5%~75%, free of dust and well ventilated |
|
|
Overall dimension |
760×720×750mm |
|
|
Machine weight |
40Kg |
|
