China Supplier 50W 100W Raycus Fiber Laser Engraving Cutting Machine For Gold Silver Jewelry

Model NO: MZ-FMD50-R
Selling Points: Fiber Laser Engraving Cutting Machine
Views:
Brand: MZLASER
Rating:
 4.9 /5 based on 182 votes


Standard Price: $4880.00 / Set
Price Range: $2000.00 to $8000.00 / Set According to Configurations
The final price will fluctuate according to the configurations of China Supplier 50W 100W Raycus Fiber Laser Engraving Cutting Machine For Gold Silver Jewelry
Supply Ability: 100 Sets / Month In stock! From - Qingdao Marking Family Laser Technology Co.,Ltd

Release time: 2020-09-24 10:26
Advantage: 50W 100W Raycus Fiber Laser Engraving Cutting Machine For Gold Silver Jewelry is very hot sale for jewelry business, it can help gold smith to do fast cutting name plate to make name necklace and also can do photos engraving on customized jewelry pendant, we can supply you Raycus,Max,JPT and IPG laser source, laser power can be optional from 50 watts, 60W 80W, 100W or 200W....

Product Introduction

Raycus 50w 100w fiber laser cutting engraving machine for gold silver jewelry with affordable price is also called name plate jewelry engraving and cutting machine, because its laser power is strong enough, so it can do not only deep engraving but also thin cutting for name plate jewelry in gold silver brass materials.Custom name jewelry business is booming and very popular, choose our 50 watts fiber laser cutting machine is a best choice to help your custom jewelry business.it can help gold smith to do fast cutting name plate to make name necklace and also can do photos engraving on customized jewelry pendant, we can supply you Raycus,Max,JPT and IPG laser source, laser power can be optional from 50 watts, 60W 80W, 100W or 200W....

Product Descriptions

China Supplier 50W 100W Raycus Fiber Laser Engraving Cutting Machine For Gold Silver Jewelry

For 50 watts fiber laser marking machine, it has full function of common fiber laser 20W 30W marking machine, but also can work faster in metal deep engraving, what's the best is that it can do customized jewelry name laser cutting on gold silver brass and other jewelry materials. It can make customized name, letters, logos, photos engraving on all metals product surface.

1) Laser cutting on gold silver brass sheet to make their custom name jewelry.
      2) Deep engrave on all metals, and do custom engraving on gift or some product to improve profit

3) Deep laser engraving machine for metal jewelry such as bracelet and rings inside engraving, photos engraving


What is max cutting thickness by Raycus 50W laser engraving machine for metal jewelry ?

1)For custom name jewelry laser cutting, they mostly laser cut gold silver, or brass, the thickness is mostly 0.8mm, maximum within 1.2mm. It can cut patterns in dxf ai and other vector file. so you can design by coreldraw or outo cad. About cutting time, it depends on the thickness of gold silver sheet and name size, for 0.5mm cutting, it usually takes about 4-6 minutes, for 0.8mm thickness, usually takes about 8-12 minutes, if 1-1.2mm, it will take around 13-16 minutes.


2)For metal engraving, such as Aluminum ,stainless steel ,carbon steel, its engraving depth can be 0.01-1.5mm by 50W fiber laser engraving machine.

Specifications of fiber laser engraving machine for metal jewelry

Product model

MZ-FMS50

MZ-FMS100

Type of machine

China Supplier 50W 100W Raycus Fiber Laser Engraving Cutting Machine For Gold Silver Jewelry

Laser Wavelength

1064nm

laser power

50W

100W

Modulating frequency

20KHz-100KHz

Marking Range:

110mm×110mm 175mm×175mm 210mm×210mm

Repetition Precision

±0.002

Marking mode

static or dynamic

Spot diameter

0.025mm

Lifting way of working

table

Manual or automatic

Lifting height

500mm

Travel of table

X:150mm   Y: 90mm

Machine power supply

220V   50Hz   20A

Cooling method

forced-air cooling

Power of the Whole Equipment

<0.5KW

working conditions

temperature:13°C~29°C, humidity:5%~75%, free of dust and well ventilated

Overall dimension

420×650×750mm

Machine weight

60Kg

50w Jewelry fiber laser engraving cutting machine display

50W fiber laser cutting machinelaser cutting machine for silver

jewelry laser engraving machinelaser engraving machine for metal price50w fiber laser marking machine supplierjewelry name plate cutting machinephoto laser engraving machine for jewelryring inside laser engraving machine

If any other questions or for more information about our Raycus 50W fiber laser marking machine for gold silver jewelry engraving and cutting, just feel free to text me on whatsapp:+8614753226012 or email to hellomike612@naver.com
