Hot sale 355nm 5W UV laser engraving machine for glass cups

Model NO: MZ-UV5
Selling Points: laser engraving machine for glass
Views:
Brand: MZLASER
Rating:
 4.9 /5 based on 182 votes


Standard Price: $4880.00 / Set
Price Range: $2000.00 to $8000.00 / Set According to Configurations
The final price will fluctuate according to the configurations of Hot sale 355nm 5W UV laser engraving machine for glass cups
Supply Ability: 100 Sets / Month In stock! From - Qingdao Marking Family Laser Technology Co.,Ltd

Release time: 2020-05-19 14:40
Advantage: People have used various forms of traditional technology to engrave glass. Unfortunately, this method has many defects. The mechanical force applied by the scoring tool will cause fine cracks in the glass. Subsequent breaking steps will cause Small gaps and debris, because the glass is particularly easy to break, it is already difficult to use traditional carving methods at this time.. 355nm 5W UV laser engraving machine is a new method to do glass custom engraving. 355nm UV laser is cold laser, it can engrave on glass products without broken product itself. ...

Product Introduction

Glass product is very common in various fields. The glass engraved by the laser marking machine can be better to show the texture of the glass, and the engraved patterns give people the feeling of coming out. People have used various forms of traditional technology to mark glass for centuries. Unfortunately, this method has many defects. The mechanical force applied by the scoring tool will cause fine cracks in the glass. Subsequent breaking steps will cause Small gaps and debris, because the glass is particularly easy to break, it is already difficult to use traditional carving methods at this time.. 355nm 5W UV laser engraving machine is a new method to do glass custom engraving. 355nm UV laser is cold laser, it can engrave on glass products without broken product itself. ...

Product Descriptions

Hot sale 355nm 5W UV laser engraving machine for glass cups


uv laser marking machine

laser engraving machine for glass cups

glass laser engravinglaser engraving machine for glass

Applications:

Mainly designed for sensitive materials to heat. UV laser will performs well in marking and engraving. For 355nm wavelength UV laser, in theory, it can work nearly all kinds of materials. Most widely applied.

UV laser is well know for glass laser engraving, ABS plastic laser marking, and IC products.

Technical specifications

Glass engraving laser machine

Hot sale 355nm 5W UV laser engraving machine for glass cups

Mode of operation       Pulsed
Polarization   random
Nominal average output power 3W - 5W
Central emission wavelength    355 nm ,Q-switched operation
Emission Bandwidth (FWHM)  <10 nm
Long-term average power instability <5%
Pulse width, (FWHM) 100 ns
Laser switching ON time 180 μsec
Laser switching OFF time 180 μsec
Pulse Repetition Rate* kHz 20-80   kHz
Energy per pulse (PRR = 20 kHz) 0.95 mJ
Typical beam quality, M2 <1.8
Output fiber delivery length 3m
Operating voltage 220V
Max. Power consumption 600W
Dimensions    75*85*145cm
Net Weight   130 kgs
Gross Weight 150 kgs
Scanning Speed 0-10000mm/s
Marking Speed     0-10000mm/s
Marking size  110mm×110mm (F-theta 160)
Spot size ≤ 40 micron   (F-theta 160)
Cooling unit Water   cooled
Pilot laser                   650nm diode laser, visible red light for marking guide
Continuous working time ≤16h
Humidity 45~85% (no condensation)
Operating temperature 0~45°C
Control units EZCAD (English Version)
